Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Overload Relay
Description
9065SF320
9065SF320 is a Square D Motor Logic overload relay designed for motor control applications with a 90 amp rating and 600 VAC voltage capacity.This thermal melting alloy overload relay features a NEMA Size 3 frame and 3 poles, suitable for separate panel mounting. It supports a current range of 30-90A and is UL listed and CSA certified for safety and reliability.
- Amperage: 90A
- Voltage: 600 VAC
- Poles: 3
- Frame Type: 9065 (NEMA Size 3)
- Sensing Method: Thermal melting alloy
- Mounting Type: Separate panel mount
- Trip Unit: Thermal overload
- Certifications: UL listed, CSA certified
- Family: Motor Logic
- Weight: Approximately 4.45 lbs
Specifications
- Part Number: 9065SF320
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Motor Control
- Item Subcategory : Overload Relay
- Family : MotorLogic
- Type : S
- Voltage : 600 AC
- Aux Contacts : 1NC
- Nema Starter Size : 3
Product Data
- UPC : 785901751953
- GTIN : 00785901751953
- Country of Origin : Mexico
- Dimensions : 5.02 in (127.5 mm) x 5.3 in (135.4 mm) x 4.4 in (113 mm) (Height x Width x Depth)
- Weight : 2.769 lb
- Certification : REACH, RoHS
