Product Info
- Manufacturer:Schneider Electric
Description
9050JCK33V14
9050JCK33V14 is a Schneider Electric plug-in interval timer relay with adjustable time delay from 0.6 to 60 seconds and DPDT contacts rated for 10 amperes.
This timing relay features a dual-pole double-throw (DPDT) contact configuration with 2 normally open and 2 normally closed silver nickel contacts. It operates on a control voltage of 24 VAC/DC and supports a maximum switching voltage of 240 VAC. The relay is designed for plug-in mounting with an 8-pin tubular socket interface and is directly interchangeable with many other 8 and 11 pin octal base timers. It is UL listed, UL recognized, CE and RoHS certified, suitable for ambient temperatures from -18 to 150 °F.
- Part Number: 9050JCK33V14
- Manufacturer: Schneider Electric
- Type: Interval Timer Relay
- Time Delay Range: 0.6 to 60 seconds
- Contact Configuration: DPDT (2 NO + 2 NC)
- Contact Rating: 10 A resistive at 120/240 VAC, 30 VDC
- Control Voltage: 24 VAC/DC
- Mounting Type: Plug-in, 8-pin tubular socket
- Contact Material: Silver nickel
- Certifications: UL listed, UL recognized, CE, RoHS
- Operating Temperature: -18 to 150 °F
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: 9050JCK33V14
- Manufacturer : Schneider Electric
- Brand : Square D
Product Data
- Country of Origin : United States
- Weight : 5.19
