Product Info
- Manufacturer:Telemecanique
- Sub-Category:Vacuum switch
Description
9016GAW1
9016GAW1 is an electromechanical vacuum switch from Telemecanique designed for sensitive control applications with adjustable differential thresholds.This vacuum switch features a 0 to 28.7 inHg sensing range with adjustable scale and two threshold settings. It has a SPDT contact configuration rated for 10A at 480VAC, housed in a durable die-cast aluminum enclosure rated NEMA 4/4X/13 for dust, oil, watertight, and corrosion resistance. The switch connects via screw clamp terminals and operates reliably within -10 to 185°F.
- Amperage Rating: 10 A
- Voltage Rating: 480 VAC
- Contact Configuration: SPDT (1NO-1NC)
- Pressure Range: 0 to 28.7 inHg vacuum
- Adjustable Differential: approx. 0.8 to 9 inHg
- Enclosure Type: NEMA 4/4X/13
- Operating Temperature: -10 to 185°F
- Connection Type: Screw Clamp Terminals
- Housing Material: Die Cast Aluminum
- Mounting Type: Panel/Chassis
- Dimensions: 6.45 in H x 4.56 in W x 4.56 in D
- Series: 9016G
Specifications
- Part Number: 9016GAW1
- Manufacturer : Telemecanique
- Brand : Telemecanique
- Category : Sensors
- Item Subcategory : Vacuum switch
- Family : 9016G
- Voltage : 480 480
Product Data
- UPC : 060648532826
- GTIN : 03606485328263
- Country of Origin : Mexico
- Dimensions : 6.45 in H x 4.56 in W x 4.56 in D
- Weight : 5
- Certification : UL 508
