9013FHG12J52 - Telemecanique Pumptrol Air Compressor Pressure Switch 150 psi 575VAC 1HP Fixed Differential 2NC DPST-dB

9013FHG12J52

9013FHG12J52 is a Telemecanique Pumptrol air compressor pressure switch designed for reliable operation in industrial applications. This fixed differential switch features a snap-action DPST-dB contact configuration and is rated for 575VAC, 1HP, with a maximum pressure of 150 psi and a fixed off point at 125 psi. The unit uses a 1/4 inch NPSF internal connection and is suitable for low horsepower systems. Engineered for durability, the 9013FHG12J52 offers a diaphragm actuator for precise pressure control and is built to conform to UL 508 standards. Its robust construction ensures long service life in demanding environments.

• Part Number: 9013FHG12J52
• Manufacturer: Telemecanique
• Series: Pumptrol 9013FH
• Maximum Pressure: 150 psi
• Fixed Differential: Off at 125 psi
• HP Rating: 1HP
• Voltage: 575VAC
• Contact Configuration: 2NC, DPST-dB
• Connection Type: 1/4 inch NPSF internal
• Actuator Type: Diaphragm
• Operating Temperature: Up to 257°F
• Certifications: UL 508

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 9013FHG12J52
• Manufacturer : Telemecanique
• Brand : Telemecanique
• Category : Sensors
• Item Subcategory : Pressure switch
• Family : 9013FH

Product Data

• UPC : 785901035640
• GTIN : 00785901035640
• Country of Origin : Mexico
• Dimensions : 2.78 in W x 3.76 in D x 3.71 in H 3.71 in H x 2.78 in W x 3.76 in D
• Weight : 1
• Certification : ANSI /NSF Standard 61, CSA Certified, FDA 21CFR.2600, NEC Article 430-84, UL 508
