9012GDW2 - Telemecanique 10A 480VAC SPDT Electromechanical Pressure Switch 1 to 40 psi NEMA 4/4X/13

9012GDW2

9012GDW2 is a Telemecanique electromechanical pressure switch designed for reliable pressure monitoring and control in industrial applications.This pressure switch features a zinc plated steel connection, SPDT contact configuration, and a contact rating of 10 A at 480 VAC. It operates within a pressure range of 1 to 40 psi with a differential of 0.6 psi ±2.5% full scale. The device is housed in a corrosion-resistant cast aluminum enclosure rated for NEMA 4, 4X, and 13 environments, suitable for dust, oil, and watertight applications. It includes a 1/2 inch NPT conduit entrance for cable entry and offers mechanical durability up to 5 million cycles with shock resistance conforming to IEC 58-2-27.

Key Specifications
• Contact Rating: 10 A at 480 VAC
• Contact Configuration: SPDT (Single Pole Double Throw)
• Pressure Range: 1 to 40 psi
• Differential: 0.6 psi ±2.5% Full Scale
• Enclosure Type: NEMA 4, 4X, 13
• Housing Material: Cast Aluminum
• Cable Entry: 1/2 inch NPT conduit
• Connection Material: Zinc Plated Steel
• Mechanical Durability: 5,000,000 cycles
• Shock Resistance: 50 gn IEC 58-2-27
• Operating Temperature: -10 to 185 °F
• Maximum Pressure: 100 psi

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 9012GDW2
• Manufacturer : Telemecanique
• Brand : Telemecanique
• Category : Sensors
• Item Subcategory : Pressure switch
• Family : 9012G

Product Data

• UPC : 785901024903
• GTIN : 00785901024903
• Country of Origin : Mexico
• Dimensions : 6.24 in H x 3.5 in W x 2.63 in D
• Weight : 3
• Certification : CE, CSA C22.2, RoHS
