2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Telemecanique
- Sub-Category:Limit Switch
Description
9007ML07S0100
9007ML07S0100 is a Telemecanique miniature potted limit switch designed for industrial automation applications with a 10 amp, 240 VAC rating.This limit switch features a single pole with a spring return parallel roller plunger actuator, metal cast zinc body, and fixed mounting by the head. It supports lateral approach in two directions and offers reliable switching with 1NO/1NC contact configuration. The device is rated for operation from -40 to 104 °C and complies with certifications including E78403 and LR 25490 Class 32 11 03.
- Key Specifications
- Amperage: 10 Amps
- Voltage: 240 VAC
- Number of Poles: 1
- Mounting Type: Fixed, by the head
- Interrupt Rating: 10A @ 240 VAC
- Series/Frame: 9007 Miniature Potted
- Trip Unit: Spring return parallel roller plunger
- Material: Cast zinc body, metal actuator
- Operating Temperature: -40 to 104 °C
- Contact Configuration: 1 Normally Open / 1 Normally Closed
- Approach Type: Lateral, 2 directions
- Certifications: E78403, LR 25490 Class 32 11 03
Specifications
- Part Number: 9007ML07S0100
- Manufacturer : Telemecanique
- Brand : Telemecanique
- Category : Sensors
- Item Subcategory : Limit Switch
- Family : 9007MS/ML
- Voltage : 120 to 240 /28 DC 120/240 , 28 DC
Product Data
- UPC : 785901493457
- Country of Origin : Mexico
- Dimensions : 1.56 in
- Weight : 5.19
- Certification : E78403 || LR 25490 Class 32 11 03; CE || UL || CSA
