9001KP1LRR31 - Square D 120V AC 30mm Red LED Pilot Light, Harmony 9001K Series, Panel Mount, Metal Bezel

9001KP1LRR31

9001KP1LRR31 is a Square D Harmony 9001K series red LED pilot light designed for motor control applications with a 120V AC rating and 30mm panel mount size.This pilot light features a chromium plated metal bezel with a Fresnel glass lens and a red plastic lens color. It uses a BA9s base with screw clamp terminals for secure wiring. The device is rated for NEMA 1/2/3/3R/4/6/12/13 and IP66 environmental protection, making it suitable for harsh industrial environments. Operating temperature ranges from -25 to 70 degrees Celsius. It is impact, dust, water, and vibration resistant and certified to international standards including Marine ABS.

Key Specifications
• Voltage: 110/120 VAC
• Size: 30 mm diameter
• Lens Color: Red
• Lens Material: Plastic Fresnel
• Bezel Material: Chromium Plated Metal
• Base Type: BA9s
• Mounting Type: Panel Mount
• Terminal Type: Screw Clamp
• Environmental Rating: NEMA 1/2/3/3R/4/6/12/13, IP66
• Operating Temperature: -25 to 70 °C
• Series: Harmony 9001K
• LED Lamp Type

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 9001KP1LRR31
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Motor Control
• Item Subcategory : Motor Control Part And Accessory
• Voltage : 110 to 120 AC

Product Data

• UPC : 785901636052
• GTIN : 00785901636052
• Country of Origin : Mexico
• Weight : 0.5
• Certification : CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C852, JIS C8201-1, JIS C8201-5-1, REACH, RoHS, UL 508, WEEE
