Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
8RBA4-65E
8RBA4-65E is an Eaton Class E standard speed expulsion fuse refill designed for reliable overcurrent protection in power distribution systems.This Type RBA4 fuse refill is rated at 65 amperes with a nominal voltage of 7.2 kV and a maximum voltage of 8.3 kV. It features a glass epoxy body construction and is intended for use in RBA fuse enclosures. The fuse provides fast-acting interruption characteristics suitable for protecting transformers and other electrical equipment.
- Type: RBA4 expulsion fuse refill
- Amperage: 65 A
- Nominal Voltage: 7.2 kV
- Maximum Voltage: 8.3 kV
- Class: E (Standard Speed)
- Body Material: Glass Epoxy
- Mounting: For RBA fuse enclosures
Specifications
- Part Number: 8RBA4-65E
- Manufacturer : Eaton
- Brand : Eaton
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Section : Fuse Refills
- Type : RBA4
- Voltage : 7200
- Amperage : 65
- AIC rating : [email protected]
- Class Rating : E
- Barrels : 1
- Velocity : Standard
Product Data
- UPC : 78667023178
- GTIN : 00786670231783
- Country of Origin : Dominican Republic
- Dimensions : 12.3 in x 2.6 in x 2.5 in (Length/Depth x Height x Width)
- Weight : 1.6
- Certification : IEEE Std. C37.41
