Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
8RBA4-300E
8RBA4-300E is a medium voltage expulsion fuse refill designed for use in Eaton RBA fuse systems. This fuse provides reliable protection for medium voltage circuits with a nominal voltage rating of 7.2 kV and a maximum voltage of 8.3 kV. It features a 300A current rating and a 1 barrel configuration, making it suitable for a variety of industrial and commercial applications. The 8RBA4-300E is an E-class fuse refill with a fast blow response time and an interrupt rating of 29.4kA at 7.2kV. It is designed for use in indoor and outdoor applications where high interrupting capacity and dependable performance are required. The fuse is compatible with standard RBA fuse holders and mounting assemblies.
- Part Number: 8RBA4-300E
- Manufacturer: Eaton
- Current Rating: 300A
- Voltage Rating: 7.2 kV nominal, 8.3 kV maximum
- Fuse Type: Expulsion, Refill
- Interrupt Rating: 29.4kA @ 7.2kV
- Mounting Type: 1 Barrel
- Series/Frame: RBA
- Response Time: Fast Blow
- Class: E
Specifications
- Part Number: 8RBA4-300E
- Manufacturer : Eaton
- Brand : Eaton
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Section : Fuse Refills
- Type : RBA4
- Voltage : 7200
- Amperage : 300
- AIC rating : [email protected]
- Class Rating : E
- Barrels : 1
- Velocity : Standard
Product Data
- UPC : 786670232186
- GTIN : 00786670232186
- Country of Origin : Dominican Republic
- Dimensions : 9.25 in x 2.5 in x 2.5 in (Length/Depth x Height x Width)
- Weight : 1.77
- Certification : IEEE Std. C37.41
