2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
8RBA4-250E
8RBA4-250E is a Type RBA4 single barrel standard speed expulsion fuse refill unit designed for medium voltage power distribution applications. This cartridge fuse delivers reliable circuit protection in industrial and utility environments where consistent performance is required. The refill unit features a glass epoxy construction and is engineered for use within RBA/RDB fuse mounting assemblies that include spring and shunt assemblies and exhaust control devices for indoor applications. Key Specifications
- Part Number: 8RBA4-250E
- Manufacturer: Eaton
- Fuse Type: Expulsion Fuse Refill Unit
- Series: Type RBA4
- Current Rating: 250A (250E)
- Voltage Rating: 8.3 kVAC
- Maximum Design Voltage: 8.25 kV
- Class: E
- Response Time: Standard Speed (Medium Blow)
- Configuration: Single Barrel
- Construction Material: Glass Epoxy
Specifications
- Part Number: 8RBA4-250E
- Manufacturer : Eaton
- Brand : Eaton
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Type : RBA4
- Voltage : 7200
- Amperage : 250
- AIC rating : [email protected]
- Class Rating : E
- Barrels : 1
- Velocity : Standard
Product Data
- UPC : 78667023212
- GTIN : 00786670232124
- Country of Origin : Dominican Republic
- Dimensions : 11 in x 2.2 in x 2.2 in (Length/Depth x Height x Width)
- Weight : 1.2
- Certification : IEEE Std. C37.41
