Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
8HLE-250E
8HLE-250E is an Eaton HLE medium voltage fuse rated for 8.3kV at 250 amperes with a 50kA interrupt rating, designed for feeder circuit, switchgear, and transformer protection applications. This Class E rated fuse features a 2-barrel ferrule-mounted design with a 3-inch diameter and 15.9-inch overall length, conforming to dimensional standards established by Westinghouse. The fuse is engineered to melt in 300 seconds at RMS current within 200% to 240% of its nameplate rating, providing reliable overcurrent protection in medium voltage distribution systems.
- Amperage Rating: 250A
- Voltage Rating: 8.3kV
- Interrupt Rating: 50kA RMS Symmetrical
- Fuse Type: Class E
- Mounting: Ferrule Mounted
- Number of Barrels: 2
- Diameter: 3 inches
- Overall Length: 15.9 inches
- Application: Feeder circuit, switchgear, and transformer protection
- Standards: Westinghouse dimensional standards
Specifications
- Part Number: 8HLE-250E
- Manufacturer : Eaton
- Brand : Eaton
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : HLE
- Type : HLE
- Voltage : 8300
- Amperage : 250
- AIC rating : [email protected]
- Diameter : 3
- Class Rating : E
- Barrels : 2
- Clip Center : 12
Product Data
- UPC : 051712531016
- GTIN : 00786670600541
- Country of Origin : Dominican Republic
- Dimensions : 15.9 in x 6.3 in x 3 in (Length/Depth x Height x Width)
- Weight : 22
- Certification : IEEE Std. C37.41 Not Applicable
