8911DPSO23V02 - Square D 25A 3-Pole 120V AC Definite Purpose Magnetic Motor Starter No Enclosure

8911DPSO23V02

This motor starter features a 25 ampere rating with a 120V AC coil voltage and supports three poles. It is rated for a maximum voltage of 600V AC and is suitable for single-phase and three-phase motors with horsepower ratings up to 20 HP at 600V AC three-phase. The starter has no enclosure (open type) and uses melting alloy overload protection. It is part of the Class 8911 series and is designed for separate control type applications.

Key Specifications
• Amperage: 25 A
• Coil Voltage: 120V AC (110V AC at 50 Hz, 120V AC at 60 Hz)
• Number of Poles: 3
• Maximum Voltage Rating: 600V AC
• Horsepower Ratings: 2 HP @ 120V AC single-phase, 5 HP @ 240V AC single-phase, 10 HP @ 240V AC three-phase, 15 HP @ 480V AC three-phase, 20 HP @ 600V AC three-phase
• Enclosure Type: No Enclosure (Open)
• Action: Non-reversing
• Series/Class: 8911
• Overload Protection: Melting Alloy
• Phase: Three

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.




Specifications

• Part Number: 8911DPSO23V02
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : Class 8911
• Type : DPS
• Voltage : 600
• Amperage : 25
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 110 VAC
• Coil Voltage Minimum : 110



Product Data

• UPC : 785901116745
• GTIN : 00785901116745
• Country of Origin : United States
• Dimensions : 3.5 in x 6.73 in
• Weight : 2.251
• Certification : REACH, RoHS, UL Listed
