8910DPA63V06 - Square D 60A 480V 3 Pole Definite Purpose Contactor DPA Series

8910DPA63V06

8910DPA63V06 is a Square D definite purpose contactor designed for motor control applications.This 3 pole, 3 phase contactor has a 60 ampere full load rating and operates at 480 volts AC. It features a panel mounting type and is suitable for use with air compressors, pumps, HVACR equipment, and agricultural machinery. The contactor is UL Recognized and CSA Certified, ensuring compliance with safety standards. It includes quick connect terminals and supports coil voltages of 440 VAC at 50 Hz and 480 VAC at 60 Hz.

• Brand: Square D
• Series: DPA
• Amperage: 60A
• Voltage: 480V AC
• Poles: 3
• Phase: 3
• Mounting Type: Panel
• Contactor Type: Definite Purpose
• Coil Voltage: 440 VAC 50 Hz / 480 VAC 60 Hz
• Certifications: UL Recognized, CSA Certified
• Terminal Type: Quick connect
• Horsepower Ratings: 5 HP at 115 V AC (1 phase), 10 HP at 230 V AC (1 phase), 30 HP at 460/575 V AC (3 phase)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 440 VAC coil.

Specifications

• Part Number: 8910DPA63V06
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Contactor
• Family : Class 8910
• Type : DPA6
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• Horse Power : 5 hp 115 V AC, 1 phase-10 hp 230 V AC, 1 phase-30 hp 460 V AC, 3 phases-30 hp 575 V AC, 3 phases-25 hp 230 V AC, 3 phases
• Aux Contacts : 3 NO
• Coil Voltage Maximum : 480V
• Full Load Amps : Full Load Amps-Inductive 60A Full Load Amps-Resistive 75A
• Coil Voltage Minimum : 440V
• Frequency : 50/60 Hz

Product Data

• UPC : 785901081135
• GTIN : 00785901081135
• Country of Origin : United States
• Dimensions : 4.1 in (105 mm) x 2.6 in (65 mm) x 3.7 in (93 mm) (Height x Width x Depth)
• Weight : 1.61
• Certification : CSA, REACH, RoHS, UL Listed
