Description
8910DPA32V09
8910DPA32V09 is a Square D definite purpose contactor designed for motor control applications with a 30 amp rating and 2 poles.This contactor features a 208/240VAC coil voltage compatible with 50/60Hz operation, suitable for 1-phase systems. It supports up to 5HP at 230VAC and includes quick connect/binder head screw terminals for easy wiring. The device is panel mountable and UL recognized and CSA certified, making it ideal for heating, air conditioning, refrigeration, and food service equipment.
- Amperage: 30A
- Voltage: 208/240VAC coil
- Poles: 2
- Phase: 1
- Mounting Type: Panel mount
- Contactor Type: Definite Purpose
- Horsepower Rating: 5HP @ 230VAC
- Connection: Quick connect/binder head screw
- Certifications: UL recognized, CSA certified
- Frequency: 50/60Hz
- Frame/Series: 8910 DPA
Additional Information
This Definite Purpose Contactor includes a 220 VAC coil.
Specifications
- Part Number: 8910DPA32V09
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 8910
- Type : DPA
- Voltage : 600
- Amperage : 30
- Phase : 1
- Poles : 2
- Horse Power : 2 hp 115 V AC, 1 phase-5 hp 230 V AC, 1 phase
- Aux Contacts : 2 NO
- Coil Voltage Maximum : 220V
- Full Load Amps : Full Load Amps-Inductive 30A Full Load Amps-Resistive 40A
- Coil Voltage Minimum : 220V
- Frequency : 50 Hz
Product Data
- UPC : 785901749813
- GTIN : 00785901749813
- Country of Origin : China
- Dimensions : 2.5 in x 4 in
- Weight : 0.98
- Certification : CSA, RoHS, UL Listed
