Description
8910DPA22V09
8910DPA22V09 is a Square D 25 amp 2-pole definite purpose contactor designed for 600V single-phase motor control applications.This contactor supports a horsepower rating of 2 HP at 115 VAC and 5 HP at 230 VAC for single-phase motors. It features an open enclosure with quick connect terminals and binder head screws for easy wiring. The device is suitable for heating, air conditioning, refrigeration, and food service equipment. It has a resistive rating of 35 amperes and is part of the Class 8910 series.
- Amperage: 25A full load, 35A resistive
- Voltage: 600V maximum
- Poles: 2
- Phase: Single-phase
- Horsepower rating: 2 HP at 115 VAC, 5 HP at 230 VAC
- Enclosure: Open type
- Mounting: Panel mount
- Series/Frame: Class 8910
- Trip Unit: Definite purpose contactor (no thermal trip)
- Terminal type: Quick connect and binder head screws
- Certifications: UL listed
Specifications
- Part Number: 8910DPA22V09
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 8910
- Type : DPA
- Voltage : 600
- Amperage : 25
- Phase : 1
- Poles : 2
- Horse Power : 2 hp 115 V AC, 1 phase-5 hp 230 V AC, 1 phase
- Aux Contacts : 2 NO
- Coil Voltage Maximum : 220V
- Coil Voltage Minimum : 220V
Product Data
- GTIN : 00785901738039
- Dimensions : Depth 4.21 in (107 mm) Width 4.25 in (108 mm) Height 3.50 in (89 mm)
- Weight : 0.98
- Certification : UL recognized CSA
