Description
8910DPA14V09
8910DPA14V09 is a Square D Class 8910 definite purpose contactor designed for motor control applications with 4-pole configuration and 20-amp contact rating at 600V. This 3-phase contactor delivers reliable switching performance for HVAC, refrigeration, and general motor control circuits with multiple voltage and horsepower ratings across single-phase and three-phase configurations. Key Specifications
- Part Number: 8910DPA14V09
- Manufacturer: Square D
- Class: 8910
- Type: Definite Purpose Contactor
- Number of Poles: 4
- Contact Configuration: 4 NO (Normally Open)
- Contact Rating: 20 Amperes
- Maximum Voltage: 600V
- Control Circuit Voltage: 220V
- Motor Power Ratings: 1.5 HP at 115V 1-Phase, 3 HP at 230V 1-Phase, 7.5 HP at 230V 3-Phase, 7.5 HP at 460V 3-Phase
Specifications
- Part Number: 8910DPA14V09
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 8910
- Type : DPA
- Voltage : 600
- Amperage : 20
- Phase : 3
- Poles : 4
- Horse Power : 1.5 hp 115 V AC, 1 phase-3 hp 230 V AC, 1 phase-7.5 hp 230 V AC, 3 phases-7.5 hp 460 V AC, 3 phases-7.5 hp 575 V AC, 3 phases
- Aux Contacts : 4 NO
- Coil Voltage Maximum : 220V
- Coil Voltage Minimum : 208
Product Data
- UPC : 785901857112
- GTIN : 00785901857112
- Dimensions : Depth 4.13 in (104.90 mm) Width 5 in (127.00 mm) Height 8.63 in (219.20 mm)
- Weight : 1.25
- Certification : UL RECOGNIZED - CSA CERTIFIED - CE MARKED
