Description
8910DPA13V06
8910DPA13V06 is a three-pole definite purpose contactor manufactured by Square D (Schneider Electric) designed for motor control applications. This non-reversing contactor features a 20 ampere full load rating with a 30 ampere resistive rating and supports multiple horsepower ratings across different voltage configurations.
- Poles: 3
- Amperage: 20A (Full Load), 30A (Resistive)
- Coil Voltage: 440/480 VAC at 50/60 Hz
- Contact Configuration: 3 NO (Normally Open)
- Motor Power Ratings: 1.5 HP at 115 VAC 1-Phase, 3 HP at 230 VAC 1-Phase, 7.5 HP at 230 VAC 3-Phase, 7.5 HP at 460/575 VAC 3-Phase
- Type: Non-reversing Definite Purpose Contactor
- Family: Class 8910
- Status: Discontinued as of July 12, 2021
Specifications
- Part Number: 8910DPA13V06
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 8910
- Type : DPA
- Voltage : 600
- Amperage : 20
- Phase : 3
- Poles : 3
- Horse Power : 1.5 hp 115 V AC, 1 phase-3 hp 230 V AC, 1 phase-7.5 hp 230 V AC, 3 phases-7.5 hp 460 V AC, 3 phases-7.5 hp 575 V AC, 3 phases
- Aux Contacts : 3 NO
- Coil Voltage Maximum : 480V
- Coil Voltage Minimum : 440V
Product Data
- UPC : 785901024316
- Weight : 1.06
- Certification : UL RECOGNIZED - CSA CERTIFIED - CE MARKED
