Description
8910DPA13V02
8910DPA13V02 is a Square D Class 8910 definite purpose contactor designed for motor control applications.This 3-pole, 3-phase contactor is rated for 20 amps and 600 volts, featuring a 110/120 VAC coil. It supports motor horsepower ratings of 1.5 HP at 115 VAC single phase, 3 HP at 230 VAC single phase, and 7.5 HP at 575 VAC three phase. The contactor is suitable for heating, air conditioning, refrigeration, and other motor control uses.
- Key Specifications
- Manufacturer: Square D
- Part Number: 8910DPA13V02
- Class: 8910
- Type: Definite Purpose Contactor (DPA)
- Amperage: 20 A
- Voltage Rating: 600 V
- Coil Voltage: 110/120 VAC, 50/60 Hz
- Poles: 3
- Phase: 3
- Horsepower Ratings: 1.5 HP @ 115 VAC, 3 HP @ 230 VAC, 7.5 HP @ 575 VAC
- Mounting: NEMA 1 enclosure
- Part Number: 8910DPA13V02
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 8910
- Type : DPA
- Voltage : 600
- Amperage : 20
- Phase : 3
- Poles : 3
- Horse Power : 1.5 hp 115 V AC, 1 phase-3 hp 230 V AC, 1 phase-7.5 hp 230 V AC, 3 phases-7.5 hp 460 V AC, 3 phases-7.5 hp 575 V AC, 3 phases
- Aux Contacts : 3 NO
- Coil Voltage Maximum : 120V
- Coil Voltage Minimum : 110V
- UPC : 785901080145
- GTIN : 00785901080145
- Dimensions : 2.31 in x 2.37 in x 2.90 in (Height x Width x Depth)
- Weight : 1.07
- Certification : UL recognized CSA
