Description
8910DP32V06
8910DP32V06 is a Square D definite purpose contactor designed for motor control applications with a 30 amp rating and 2 poles.This 1 phase contactor operates at 600V AC with a coil voltage of 440/480V AC at 50/60 Hz. It supports horsepower ratings of 2 HP at 115V AC and 5 HP at 230V AC. The device features quick connect terminals and binder head screws for easy wiring and is ideal for heating, air conditioning, refrigeration, and other industrial equipment.
- Manufacturer: Square D
- Part Number: 8910DP32V06
- Type: Definite Purpose Contactor
- Poles: 2
- Phase: 1
- Rated Current: 30 Amps
- Voltage Rating: 600V AC
- Coil Voltage: 440/480V AC 50/60 Hz
- Horsepower Rating: 2 HP at 115V AC, 5 HP at 230V AC
- Mounting: Quick connect terminals with binder head screws
- Application: Motor control, HVAC, refrigeration
Additional Information
This Definite Purpose Contactor includes a 440 VAC coil.
Specifications
- Part Number: 8910DP32V06
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 8910
- Type : DP
- Voltage : 600
- Amperage : 30
- Phase : 1
- Poles : 2
- Horse Power : 2 hp 115 V AC, 1 phase-5 hp 230 V AC, 1 phase
- Aux Contacts : 2 NO
- Coil Voltage Maximum : 480V
- Full Load Amps : Full Load Amps-Inductive 30A Full Load Amps-Resistive 40A
- Coil Voltage Minimum : 440V
- Frequency : 50/60 Hz
Product Data
- UPC : 785901744399
- GTIN : 00785901744399
- Country of Origin : Mexico
- Dimensions : 2.008 in (51 mm) x 3.3 in (84 mm) x 2.4 in (62 mm) (Height x Width x Depth)
- Weight : 0.51
- Certification : CSA, REACH, RoHS, UL Listed
