8910DP31V09 - Square D 30A 1 Pole 600V Definite Purpose Contactor for Motor Control

8910DP31V09

8910DP31V09 is a Square D Class 8910 Definite Purpose Contactor designed for reliable motor control applications. This 1 pole, 30A contactor supports up to 600V AC and is ideal for single-phase motor loads. It features a 240V coil, quick-connect terminals, and a non-replaceable coil for secure operation. The contactor is rated for 2HP at 115V and 3HP at 230V, making it suitable for a wide range of commercial and industrial uses.Engineered for durability and ease of installation, the 8910DP31V09 is built to meet the demands of motor control circuits. Its compact design and robust construction ensure long-term reliability in demanding environments.

• Part Number: 8910DP31V09
• Manufacturer: Square D
• Series: Class 8910
• Amperage: 30A
• Maximum Voltage: 600V AC
• Poles: 1
• Coil Voltage: 240V AC
• Mounting Type: DIN Rail or Panel Mount
• Interrupt Rating: 10kA
• Frame: 8910
• Application: Motor Control
• HP Rating: 2HP @ 115V, 3HP @ 230V

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 220 VAC coil.

Specifications

• Part Number: 8910DP31V09
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Contactor
• Family : Class 8910
• Type : DP
• Voltage : 600
• Amperage : 30
• Phase : 1
• Horse Power : 2 hp 115 V AC, 1 phase-3 hp 230 V AC, 1 phase
• Aux Contacts : 1 NO
• Coil Voltage Maximum : 220V
• Full Load Amps : Full Load Amps-Inductive 30A Full Load Amps-Resistive 40A
• Coil Voltage Minimum : 220V
• Frequency : 50 Hz

Product Data

• UPC : 078590102417
• GTIN : 00785901024170
• Country of Origin : China
• Dimensions : 2.008 in (51 mm) x 3.3 in (84 mm) x 2.4 in (61 mm) (Height x Width x Depth)
• Weight : 0.5
• Certification : CSA, REACH, RoHS, UL Listed
