Description
8910DP22V09
8910DP22V09 is a two-pole definite purpose non-reversing contactor manufactured by Square D (Schneider Electric) designed for motor control applications. This contactor features a full load current rating of 25 amperes for inductive loads and 35 amperes for resistive loads, making it suitable for controlling single-phase motors up to 3 horsepower at 230V or 2 horsepower at 120V. The unit has a nonreplaceable coil and operates at 208/240VAC with 50/60 Hz frequency capability.
- Number of Poles: 2
- Full Load Current (Inductive): 25 A
- Full Load Current (Resistive): 35 A
- Coil Voltage: 208/240VAC
- Frequency: 50/60 Hz
- Horsepower @ 1 Phase - 230V: 3 hp
- Horsepower @ 1 Phase - 120V: 2 hp
- Type: Non-Reversing Definite Purpose Contactor
- Height: 3.29 in
- Maximum Voltage Rating: 600VAC
Specifications
- Part Number: 8910DP22V09
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 8910
- Type : DP
- Voltage : 600
- Amperage : 25
- Phase : 1
- Poles : 2
- Horse Power : 2 hp 115 V AC, 1 phase-3 hp 230 V AC, 1 phase
- Aux Contacts : 2 NO
- Coil Voltage Maximum : 220V
- Coil Voltage Minimum : 220V
Product Data
- GTIN : 00785901073321
- Dimensions : Depth 4.13 in (104.90 mm) Width 4.5 in (114.30 mm) Height 6.4 in (162.56 mm)
- Weight : 0.55
- Certification : UL recognized CSA
