Description
8910DP21V14
8910DP21V14 is a Square D definite purpose contactor designed for motor control applications with a 25 amp rating and 1 pole configuration.
This contactor features a 24V AC coil operating at 50/60 Hz, suitable for controlling motors up to 2 HP at 115V single-phase and 3 HP at 230V single-phase. It has an open NEMA construction without an enclosure, providing reliable switching for definite purpose motor loads.
- Key Specifications
- Manufacturer: Square D
- Part Number: 8910DP21V14
- Amperage: 25 Amps
- Poles: 1 Pole
- Coil Voltage: 24V AC, 50/60 Hz
- Motor Power Rating: 2 HP at 115V 1 Phase, 3 HP at 230V 1 Phase
- Enclosure: Open (No NEMA enclosure)
- Series: Class 8910
- Part Number: 8910DP21V14
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 8910
- Type : DP
- Voltage : 600
- Amperage : 25
- Phase : 1
- Poles : 1
- Horse Power : 2 hp 115 V AC, 1 phase-3 hp 230 V AC, 1 phase
- Aux Contacts : 1 NO
- Coil Voltage Maximum : 24V
- Coil Voltage Minimum : 24V
- GTIN : 00785901748632
- Dimensions : Depth 4.13 in (104.90 mm) Width 4.5 in (114.30 mm) Height 6.4 in (162.56 mm)
- Weight : 0.51
- Certification : UL recognized CSA
