8903LXG1000V02 - Square D 30A 600VAC 10-Pole Mechanically Held Lighting Contactor NEMA 1

8903LXG1000V02

8903LXG1000V02 is a Square D Class 8903 multipole lighting contactor designed for reliable lighting control applications. This mechanically held contactor features a NEMA 1 enclosure and is rated for 30A at 600VAC, with a 110/120VAC coil for 50/60Hz operation. It includes 10 poles and 10NO auxiliary contacts, making it ideal for large-scale lighting and electrical heating control systems. Engineered for durability and flexibility, this contactor offers field-convertible contacts with clear NO/NC indicators, allowing for thousands of possible contact configurations. It is UL and CSA approved, ensuring compliance with industry safety standards. The compact design and robust construction make it suitable for a wide range of commercial and industrial environments.

• Manufacturer: Square D
• Part Number: 8903LXG1000V02
• Series: Class 8903
• Type: Mechanically Held
• Enclosure: NEMA 1
• Amperage: 30A
• Voltage: 600VAC
• Coil Voltage: 110/120VAC 50/60Hz
• Poles: 10
• Contacts: 10NO
• Approvals: UL, CSA
• Application: Lighting Control, Electrical Heating

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This includes a 110 VAC coil.

Specifications

• Part Number: 8903LXG1000V02
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Contactor
• Family : Class 8903
• Type : LX
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 10
• Coil Voltage Maximum : 120
• Full Load Amps : 30
• Coil Voltage Minimum : 110

Product Data

• UPC : 785901057444
• GTIN : 00785901057444
• Country of Origin : Mexico
• Dimensions : 12.7 in (322 mm) x 7.8 in (198 mm) x 6.02 in (153 mm) (Height x Width x Depth)
• Weight : 12.181
• Certification : UL Listed; CSA
