Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Contactor
Description
8903LW60V04
8903LW60V04 is a Square D multipole lighting contactor designed for reliable motor control applications. This contactor features an electrically held design, 6 poles, and a NEMA 1 enclosure for indoor use. The 8903LW60V04 contactor is rated for 30A at 600V, with a 277V AC 60 Hz coil. It is suitable for fluorescent and tungsten lighting loads, offering 6 normally open (NO) contacts. The rugged construction supports demanding electrical environments and is field-convertible for flexible installation.
- Manufacturer: Square D
- Series: 8903
- Amperage: 30A
- Voltage: 600V
- Poles: 6
- Contact Configuration: 6 NO
- Coil Voltage: 277V AC 60 Hz
- Enclosure Type: NEMA 1
- Mounting Type: Electrically Held
- Application: Lighting and Motor Control
- Standards: UL Listed, CSA Certified
Specifications
- Part Number: 8903LW60V04
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 8903
- Type : L
- Voltage : 600
- Amperage : 30
- Phase : 3
- Poles : 6
- Coil Voltage Maximum : 277
Product Data
- Country of Origin : Mexico
- Dimensions : 16.2 in (411 mm) x 8.1 in (206 mm) x 7.9 in (200 mm) (Height x Width x Depth)
- Weight : 21.78
- Certification : UL listed - CSA
