8536SFO1V06H30 - Square D 135A 600VAC 3 Pole NEMA Size 4 Motor Starter Non-Reversing

8536SFO1V06H30

8536SFO1V06H30 is a Square D Class 8536 NEMA motor starter designed for reliable full-voltage starting and stopping of three-phase AC motors. This non-reversing starter features a 135A current rating, 600VAC maximum voltage, and is built to NEMA Size 4 standards for robust industrial applications. The 8536SFO1V06H30 starter is equipped with a 480VAC coil and utilizes Motor Logic™ solid-state overload protection for precise motor control. It is suitable for a wide range of motor horsepower ratings and is designed for easy installation and maintenance in demanding environments.

• Part Number: 8536SFO1V06H30
• Manufacturer: Square D
• Series: 8536
• NEMA Size: 4
• Amperage Rating: 135A
• Maximum Voltage: 600VAC
• Number of Poles: 3
• Coil Voltage: 480VAC at 60Hz
• Frequency Rating: 50/60 Hz
• Overload Protection: Motor Logic™ Solid-State
• Interrupt Rating: 100 kA at 480VAC
• Mounting Type: Open Enclosure
• Reversing Capability: Non-Reversing
• Standards: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 8536SFO1V06H30
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : Class 8536
• Type : SFO
• Voltage : 6
• Amperage : 135
• Poles : 3
• Horse Power : HP @ 3 Phase - 208V 40 hp HP @ 3 Phase - 240V 50 hp HP @ 3 Phase - 480V 100 hp
• Configuration : Nonreversing
• Aux Contacts : 1NO
• Coil Voltage Maximum : 480 VAC
• Coil Voltage Minimum : 440
• Nema Starter Size : 4

Product Data

• UPC : 785901811466
• GTIN : 00785901811466
• Country of Origin : Mexico
• Dimensions : 12.88 in (327.15 mm) x 6.00 in (152.40 mm) x 6.50 in (165.10 mm) (Height x Width x Depth)
• Weight : 27.21
• Certification : CSA, UL Listed
