8536SCO2V02S - Square D 36A 2 Pole 1 Phase 120VAC NEMA 1P Motor Starter Non-Reversing

8536SCO2V02S

8536SCO2V02S is a Square D motor starter designed for 1 phase applications with a 36 amp rating and 2 poles, featuring a 120VAC coil voltage and NEMA 1P frame.This full voltage, non-reversing motor starter supports up to 5 HP at 230 VAC and 3 HP at 120 VAC single phase motors. It has a 5 kiloamp interrupt rating (SCCR) and an open enclosure type built to NEMA standards. The starter requires separate heater packs and is suitable for control circuits operating at 110/120 VAC 50/60 Hz.

• Amperage: 36 Amps
• Voltage: 120 VAC coil, 600 VAC max operating voltage
• Poles: 2
• Phase: Single phase
• Mounting Type: NEMA 1P frame
• Interrupt Rating: 5 kA SCCR
• Type: Full voltage, non-reversing
• Enclosure: Open
• Horsepower: 3 HP @ 120 VAC, 5 HP @ 230 VAC
• Control Voltage: 110/120 VAC 50/60 Hz
• Trip Unit: Magnetic starter
• Certifications: Meets NEMA standards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 8536SCO2V02S
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Motor Starter
• Voltage : 600
• Amperage : 27
• Phase : 1
• Poles : 2
• Coil Voltage Maximum : 120 VAC
• Nema Rating : 1

Product Data

• UPC : 785901608707
• GTIN : 00785901608707
• Country of Origin : Mexico
• Dimensions : 6.81 in (172.96 mm) x 3.50 in (88.90 mm) x 4.22 in (107.19 mm) (Height x Width x Depth)
• Weight : 3.971
• Certification : UL Listed; CSA; NEMA
