8536SAO12V08 - Square D 9A 600VAC 3-Pole NEMA 00 Motor Starter 208V Coil Open Enclosure Non-Reversing

8536SAO12V08

8536SAO12V08 is a Square D NEMA 00 motor starter designed for reliable motor control with a 9 amp rating and 208 VAC coil voltage.This 3-pole, non-reversing motor starter supports motor horsepower ratings of 1.5 HP at 200/230 VAC and 2 HP at 460/575 VAC. It features an open enclosure type, thermal melting alloy overload relay, and screw clamp connections. The starter is built for durability with a robust design, serviceable parts, and compliance with NEMA standards.

• Amperage Rating: 9 Amps
• Voltage Rating: 600 VAC
• Coil Voltage: 208 VAC, 60 Hz
• Number of Poles: 3
• Motor Power: 1.5 HP at 200/230 VAC, 2 HP at 460/575 VAC
• Enclosure Type: Open
• Type: Non-Reversing
• Series/Frame: 8536, Size 00
• Overload Relay: Thermal Melting Alloy
• Connection Type: Screw Clamp
• Frequency: 50/60 Hz
• Country of Origin: US

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

Non-Reversing

Specifications

• Part Number: 8536SAO12V08
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : Class 8536
• Type : SAO
• Voltage : 6
• Amperage : 9 Amp
• Phase : 3
• Poles : 3
• Horse Power : HP @ 3 Phase - 208V 1 1/2 hp HP @ 3 Phase - 240V 1 1/2 hp HP @ 3 Phase - 480V 2 hp
• Configuration : Nonreversing
• Aux Contacts : Not Applicable
• Coil Voltage Maximum : 208 VAC
• Nema Starter Size : 0

Product Data

• UPC : 785901743460
• GTIN : 00785902000000
• Country of Origin : Mexico
• Dimensions : 6.81 in (172.96 mm) x 3.50 in (88.90 mm) x 4.22 in (107.19 mm) (Height x Width x Depth)
• Weight : 4.061
• Certification : CSA, UL Listed
