8536SAG12V03 - Square D 9A 600V 3 Pole Motor Starter NEMA 1 Enclosure Size 00 Full Voltage Non-Reversing

8536SAG12V03

8536SAG12V03 is a Square D Class 8536 motor starter designed for full voltage starting and stopping of AC squirrel cage motors.8536SAG12V03 is a 3 pole, 3 phase motor starter with a 9 ampere rating and 600V system voltage. It features a NEMA 1 general purpose painted sheet steel enclosure sized at 10 x 6 x 5.56 inches. This Size 00 non-reversing starter supports motor horsepower ratings of 1.5 HP at 208-230 VAC and 2 HP at 460-575 VAC. It includes a melting alloy type overload relay with Type B thermal units for overload protection and has a 5 kA short circuit current rating (SCCR) per UL508A when protected by appropriate breakers or fuses. The starter coil operates at 220/240 VAC 50/60 Hz wired for common control. This product is UL listed and CSA certified.

Key Specifications
• Manufacturer: Square D
• Part Number: 8536SAG12V03
• Amperage: 9 Amps
• Voltage: 600 VAC system, 220/240 VAC coil
• Poles: 3
• Phase: 3
• Mounting Type: Surface mount
• Enclosure: NEMA 1 general purpose
• Size: 00
• Interrupt Rating: 5 kA SCCR
• Overload Relay: Melting alloy with Type B thermal units
• Certifications: UL listed, CSA certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

Non-Reversing

Specifications

• Part Number: 8536SAG12V03
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : Class 8536
• Type : SAG
• Voltage : 6
• Amperage : 9 Amp
• Phase : 3
• Poles : 3
• Horse Power : HP @ 3 Phase - 208V 1 1/2 hp HP @ 3 Phase - 240V 1 1/2 hp HP @ 3 Phase - 480V 2 hp
• Configuration : Nonreversing
• Aux Contacts : Not Applicable
• Coil Voltage Maximum : 240 VAC
• Coil Voltage Minimum : 220
• Nema Starter Size : 0

Product Data

• UPC : 785901743491
• GTIN : 00785901743491
• Country of Origin : Mexico
• Dimensions : 10.00 in (254.00 mm) x 6.00 in (152.40 mm) x 5.56 in (141.22 mm) (Height x Width x Depth)
• Weight : 7.339
• Certification : CSA, UL Listed
