8502SBO1V02 - Square D NEMA Type S 2-Pole 18A 120VAC Non-Reversing Contactor

8502SBO1V02

8502SBO1V02 is a NEMA Type S non-reversing contactor manufactured by Square D for motor control applications. This compact, open-type contactor is designed for single-phase power distribution and motor starting in industrial and commercial settings.Technical Specifications: The contactor features a 2-pole configuration with an 18-ampere operating current rating. The control circuit operates at 120 VAC coil voltage. As a NEMA Size 0 unit, it delivers 1 HP at 115 VAC and 2 HP at 230 VAC for single-phase applications. The non-reversing design ensures unidirectional motor control without reversing capability. The open enclosure type allows for integration into custom control panels and cabinets.Key Specifications

• Part Number: 8502SBO1V02
• Manufacturer: Square D
• Contactor Type: NEMA Type S Non-Reversing
• NEMA Size: 0
• Poles: 2
• Operating Current: 18 Amperes
• Coil Voltage: 120 VAC
• Horsepower Rating: 1 HP at 115 VAC, 2 HP at 230 VAC (single-phase)
• Enclosure Type: Open
• Weight: 3.00 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This NEMA Type S Contactor includes a 110 VAC coil.

Specifications

• Part Number: 8502SBO1V02
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Contactor
• Family : Class 8502
• Type : SBO
• Voltage : 600
• Amperage : 18
• Phase : 1
• Poles : 2
• Configuration : Non-Reversing
• Aux Contacts : Auxiliary Contacts Not Included
• Coil Voltage Maximum : 120
• Nema Starter Size : 0
• Frequency : 50/60 Hz

Product Data

• UPC : 78590176150
• GTIN : 00785901761501
• Country of Origin : Mexico
• Dimensions : 4.34 in (110.24 mm) x 3.22 in (81.79 mm) x 4.22 in (107.19 mm) (Height x Width x Depth)
• Weight : 3.261
