8501RSD42M1P14V53 - Square D 10A 240VAC 2-Pole Double Throw Miniature Relay with 24VDC Coil

8501RSD42M1P14V53

8501RSD42M1P14V53 is a Square D miniature relay designed for reliable switching in control circuits.This relay features a 10 ampere current rating at 240 VAC, 2-pole double throw (DPDT) contact configuration, and a 24 VDC coil voltage. It includes an 8-blade socket mounting style, a manual operator, pilot light, and test button for easy operation and status indication. The relay is suitable for use in adverse environments with a wide operating temperature range from -40°C to 55°C. It provides long mechanical life and high contact reliability for industrial and commercial applications.

Key Specifications
• Amperage: 10 A resistive at 240 VAC
• Voltage: 240 VAC switching voltage
• Coil Voltage: 24 VDC
• Poles: 2 poles (DPDT)
• Mounting Type: Plug-in socket with 8 blades
• Contact Configuration: Double Pole Double Throw (DPDT)
• Features: Manual operator, pilot light, test button
• Operating Temperature: -40°C to 55°C
• Mechanical Life: Long life for high speed operation
• Certifications: UL 508 compliant
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: 8501RSD42M1P14V53
• Manufacturer : Schneider Electric
• Brand : Square D



Product Data

• GTIN : 00785901137108
• Country of Origin : China
• Dimensions : 1.07 in (27.3 mm) x 0.8 in (21 mm) x 1.6 in (41.8 mm) (Height x Width x Depth)
• Weight : 5.19
