Description
8408
8408 is a two-conductor, 16 AWG low-impedance analog audio cable designed for balanced audio signal transmission with high durability.8408 features stranded tinned copper conductors with EPDM rubber insulation, a rayon braid, and an 85% coverage tinned copper braid shield, all protected by a heavy-duty CSPE jacket. It operates reliably in temperatures from -30°C to +60°C and is suitable for indoor use with VW-1 flame rating. This cable complies with EU CE, RoHS, and WEEE directives, ensuring environmental safety and quality.
- Key Specifications
- Conductor: 2 conductors, 16 AWG stranded tinned copper
- Insulation: EPDM rubber
- Shield: Rayon braid and 85% tinned copper braid
- Jacket: CSPE heavy-duty
- Overall Diameter: 0.380 inches (9.65 mm)
- Operating Temperature: -30°C to +60°C
- Max Pulling Tension: 150 lbs (68 kg)
- Flame Rating: VW-1
- Compliance: EU CE Mark, RoHS 2, WEEE, China RoHS II
- Application: Balanced analog audio, low-impedance signal
Specifications
- Part Number: 8408
Product Data
- Weight : 5.19
