8018 - Emery Jensen Distribution LLC 8-Channel Thermocouple/mV Data Acquisition Module, 16-Bit, RS-485 Interface

8018

This module features 16-bit resolution and supports multiple thermocouple types (J, K, T, E, R, S, B, N, C) and millivolt inputs with selectable input ranges. It communicates via RS-485 interface with terminal block connections and operates on a DC power supply ranging from 10 to 30 volts. The device offers high accuracy of ±0.1%, photo isolation of 3750 Vrms, and robust environmental tolerance including operating temperatures from -25 to 75°C.

Key Specifications
• Input Channels: 8 differential or 6 differential + 2 single-ended (jumper selectable)
• Input Types: Thermocouple (J, K, T, E, R, S, B, N, C), ±15mV to ±2.5V, ±20mA (with resistor)
• Resolution: 16 bit
• Sampling Rate: 10 samples per second
• Accuracy: ±0.1%
• Interface: RS-485, format N,8,1, baud rate 1200–115200 bps
• Power Supply: +10 to +30 V DC
• Photo Isolation: 3750 Vrms
• Operating Temperature: -25 to 75°C (-13 to 167°F)
• Power Consumption: 1.0 W

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.




Specifications

• Part Number: 8018
• Manufacturer : Emery Jensen Distribution LLC
• Brand : The Magnet Source



Product Data

• UPC : 095421080182
• GTIN : 00042526080180
• Country of Origin : China
• Weight : 5.19
