2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Allen-Bradley
Description
800T-JG141A
800T-JG141A is a 30mm selector switch manufactured by Allen-Bradley with 3 positions and spring return functionality from both left and right. This industrial control switch features a metal wing lever operator and is designed for use in NEMA 1, 4, 12, and 13 enclosures. The switch supports both AC and DC applications with a maximum operational voltage of 600V and a thermal current rating of 10A. It is rated for AC utilization category A600/AC-15 and DC utilization category Q600/DC-13, with an operational design life of 1,000,000 cycles. Key Specifications
- Part Number: 800T-JG141A
- Manufacturer: Allen-Bradley
- Switch Type: Selector Switch
- Number of Positions: 3
- Operator Function: Spring return from left and right
- Voltage Rating: 600V AC @ 600V DC
- Current Rating: 10A
- Utilization Category AC: A600, AC-15
- Utilization Category DC: Q600, DC-13
- NEMA Enclosure Compatibility: 1, 4, 12, 13
- Mechanical Design Life: 1,000,000 cycles
- Electrical Design Life: 1,000,000 cycles
- Hole Diameter: 30.5mm
Specifications
- Part Number: 800T-JG141A
- Manufacturer : Allen-Bradley
- Brand : Allen-Bradley
- Category : Switch
- Voltage : 600V AC @ 600V DC
- Amperage : 10A
- Functions : Spring return from left and right
- Diameter : 30.5mm
- Class Rating : A600 (AC), Q600 (DC)
- Switch Style : 3-Position
- Nema Rating : 1, 4, 12, 13
- Switch Type : Selector Switch
- Enclosure Type : NEMA 1, 4, 12, 13
