800T-FXPH16RA1 - Allen-Bradley 30mm Illuminated Push-Pull Mushroom Head Push Button, 10A, 120V AC, 2-Position, LED, Standard Block

800T-FXPH16RA1

800T-FXPH16RA1 is a 30mm illuminated push-pull push button from Allen-Bradley featuring a red mushroom head and LED illumination.This push button offers a 2-position push-pull operator function with a round mushroom head made of plastic with aluminum spinover. It includes a transformer-type LED illumination module rated for 120V AC at 50/60 Hz. The contact block has a thermal current rating of 10A and supports utilization categories A600 (AC) and Q600 (DC) with a maximum operational voltage of 600V AC/DC. The device is designed for mounting in 30.5mm diameter holes and is compatible with NEMA 1, 4, 12, and 13 enclosures. It has a mechanical design life of at least 250,000 cycles and comes factory assembled with 1 normally closed and 1 normally open contact block.

Key Specifications
• Operator Cap Size: 40 mm
• Contact Configuration: 1 NO, 1 NC
• Illumination: LED with Transformer Module
• Voltage Rating: 120V AC 50/60 Hz
• Thermal Current Rating: 10A
• Operator Function: Push-Pull, 2-Position
• Head Type: Mushroom Head (Push-Pull)
• Mounting Hole Diameter: 30.5 mm
• Enclosure Compatibility: NEMA 1, 4, 12, 13
• Mechanical Life: 250,000 cycles minimum
• Contact Block Type: Standard
• Certifications: CE, CSA, UL Listed, CCC, KC, MARINE

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 800T-FXPH16RA1
• Manufacturer : Allen-Bradley
• Brand : Allen-Bradley
• Category : Automation
• Item Subcategory : Motor Control Part And Accessory

Product Data

• Weight : 5.19
