800FM-SR32 Allen-Bradley 22mm Metal Selector Switch, 3-Position Spring Return from Right

800FMSR32

800FM-SR32 Allen-Bradley 22mm Metal Selector Switch, 3-Position Spring Return from Right

The Allen-Bradley 800FM-SR32 is a 22.5 mm metal selector switch operator from the Bulletin 800F PB line, configured for 3-position operation with spring return from the right. The left and center positions are maintained; the right position is momentary and spring returns to center. The die-cast zinc alloy operator with chromate plating carries a standard black knob with white insert in standard orientation and is non-illuminated with no power module. It is rated Type 4/13 and IP66 and is listed to UL and CSA, with additional cUL, CCC, KC, and Marine certifications. At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

The 800FM-SR32 ships as an operator only. A 22.5 mm mounting latch and 800F contact blocks (800F-X10 N.O. or 800F-X01 N.C.) are required to complete a functional station and are ordered separately.

Common Applications

• Hand-Off-Jog and Run-Off-Momentary control on motor starter panels
• 3-position selection where one position must self-return to center
• Industrial machine control and operator interface stations
• Panel builds requiring UL, CSA, and CCC compliant pilot devices

Key Features

• 3-Position Spring Return: Left and center maintained, right position momentary and spring returns to center.
• Metal Operator: Die-cast zinc alloy with chromate plating for durable industrial service.
• 22.5 mm Mount: Standard panel cutout compatible with 800F latches and contact blocks.
• Sealed Rating: Type 4/13 and IP66 operator for washdown and dusty environments.
• Global Listings: UL, CSA, cUL, CCC, KC, and Marine certified.

Specifications

• Catalog Number: 800FM-SR32
• Type: 22mm selector switch operator, 800F PB
• Positions: 3
• Action: Spring return from right (momentary); left and center maintained
• Operator Material: Metal, die-cast zinc alloy, chromate plated
• Knob: Standard black knob, white insert, standard orientation
• Illumination: None (no power module)
• Mounting: 22.5 mm round panel cutout
• Enclosure Rating: Type 4/13, IP66
• Operating Temperature: -25 C to +70 C
• Certifications: UL, CSA, cUL, CCC, KC, Marine
• Lifecycle: Active

Product Identification

• UPC: 662073818076
• Mounting Cutout: 22.5 mm round
• Configuration: Operator only; contact blocks and latch sold separately

FAQ

What is the 800FM-SR32? It is an Allen-Bradley 22mm metal selector switch operator, 3-position with spring return from the right.

Does it include contact blocks? No. It is an ope

Specifications

• Part Number: 800FMSR32
• Manufacturer : Allen-Bradley
• Brand : Allen-Bradley
• Category : Motor Control
• Item Subcategory : Motor Control Part And Accessory

Product Data

• UPC : 662073818076
• GTIN : 00662073818076
• Dimensions : 73 x 52 x 36 mm
• Weight : 0.04 lb
