Product Info
- Manufacturer:Littelfuse
- Sub-Category:Medium Voltage Fuse
Description
712100
712100 is a Littelfuse 217 Series 5x20mm fast-acting cartridge fuse rated at 1 amp and 250 volts AC.This fuse features a glass body designed to meet IEC 60127-2, Sheet 2 specifications for fast-acting fuses. It offers reliable overcurrent protection with a nominal melting current of approximately 1.042 A at 2 seconds and a resistance of 0.09635 ohms. The fuse is suitable for use in a wide temperature range from -55°C to 125°C and is RoHS compliant and lead-free. It is designed for global applications requiring IEC standard fuses.
- Series: 217
- Fuse Type: Fast-Acting Cartridge
- Size: 5x20 mm
- Current Rating: 1 Amp
- Voltage Rating: 250 Volts AC
- Nominal Melting I2t: 1.042 A²s (2 seconds)
- Resistance: 0.09635 Ohms
- Operating Temperature: -55°C to 125°C
- IEC Standard: IEC 60127-2, Sheet 2
- RoHS Compliant and Lead-Free
Specifications
- Part Number: 712100
- Manufacturer : Littelfuse
- Brand : Littelfuse
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Section : Fuse Refills
- Family : Plunger Switch Accessories
- Type : Plunger Switch Accessories
- Voltage : 17000
- Amperage : 100
- Class Rating : E
- Mounting : Condenser
Product Data
- UPC : 66245997891
- GTIN : 00662459978912
- Weight : 1
