Product Info
- Manufacturer:Littelfuse
- Sub-Category:Medium Voltage Fuse
Description
702R1C5.5
702R1C5.5 is a Littelfuse R-Rated medium voltage fuse designed for reliable short-circuit protection in motor and motor controller applications. This cartridge-style fuse provides precise current limiting and is engineered for use in demanding industrial environments where high interrupting capacity is required.Engineered for medium voltage systems, the 702R1C5.5 offers robust protection for motors, controllers, and associated circuitry. Its R-Rated design ensures compliance with NEMA standards for medium voltage power fuses, providing fast response to short-circuit events while supporting overload and locked rotor protection through compatible controllers. The fuse is constructed for durability and safety in high-energy applications.
- Amperage Rating: 70A
- Voltage Rating: 5.5 kVAC
- Interrupt Rating: 80 kA @ 5.5 kVAC
- Fuse Type: R-Rated
- Mounting Type: Cartridge
- Series: POWR-GARD
- Protection Type: Medium Voltage
- Application: Motor Protection
- Current Limiting: Yes
- Frame: Single Barrel
Specifications
- Part Number: 702R1C5.5
- Manufacturer : Littelfuse
- Brand : Littelfuse
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : R Rated
- Type : R Rated
- Voltage : 5500
- Amperage : 70
- AIC rating : [email protected]
- Diameter : 3
- Class Rating : R
- Barrels : 1
- Clip Center : 12
Product Data
- UPC : 079458041668
- GTIN : 00079458041668
- Weight : 9
