Product Info
- Manufacturer:Allen-Bradley
- Sub-Category:Control Relay
Description
700-K22Z-DJ
700-K22Z-DJ is an Allen-Bradley IEC miniature control relay designed for motor control applications with a 24 V DC coil and 4 poles rated at 10 A.This 700 Series 700K relay features a compact low-profile design with screw terminal connections and a contact voltage rating of 690 V AC, suitable for DIN rail or panel mounting.
- Coil Voltage: 24 V DC
- Number of Poles: 4
- Contact Current Rating: 10 A
- Contact Voltage Rating: 690 V AC
- Contact Configuration: 2 Normally Open (NO) + 2 Normally Closed (NC)
- Mounting Type: DIN Rail or Panel Mount
- Terminal Type: Screw
- Operating Temperature Range: -55°C to +60°C
- Series/Frame: 700 Series, 700K
- Certifications: IEC/EN 60947-1, UL 508, CSA 22.2 No. 14, CE marked, cULus listed
- Dimensions: Approx. 44.9 mm W x 108.2 mm L x 78.7 mm D
Specifications
- Part Number: 700-K22Z-DJ
- Manufacturer : Allen-Bradley
- Brand : Allen-Bradley
- Category : Motor Control
- Item Subcategory : Control Relay
Product Data
- Weight : 0.44 lb
