Product Info
- Manufacturer:S&C Electric
- Sub-Category:Medium Voltage
Description
614100
614100 is a medium voltage power fuse manufactured by S&C Electric, designed for reliable circuit protection in demanding electrical distribution systems. This single-barrel fuse unit is rated for 34.5 kV nominal voltage with a maximum rating of 38 kV, and provides 100 amperes continuous current capacity. The SMU-20 fuse unit features porcelain insulators and copper fittings for superior durability and performance in outdoor and indoor applications.
- Rated Voltage: 34.5 kV Nominal, 38 kV Maximum
- Amperage Rating: 100 Amperes
- Fuse Type: SMU-20 Standard Speed
- Interrupting Rating: 6,250 Amperes RMS Symmetrical
- BIL Rating: 150 kV
- Mounting: Single-Barrel Design
- Insulation Material: Porcelain
- Fittings: Copper
- Resistance: 0.806 milliohms Average
Specifications
- Part Number: 614100
- Manufacturer : S&C Electric
- Brand : S&C Electric
- Category : Fuse
- Item Subcategory : Medium Voltage
- Type : SMU-20
- Voltage : 34500
- Amperage : 100
- Class Rating : E
- Barrels : 1
- Velocity : Standard
Product Data
- Weight : 2
