Product Info
- Manufacturer:Eaton
- Sub-Category:Fuse Block
Description
60307
60307 is a 30 amp, 600 volt Class H/K fuse block manufactured by Eaton (Mersen) designed for secure fuse installation with reinforced clip retention.60307 features a 2-pole configuration suitable for both AC and DC applications up to 600 volts. It supports Class H/K fuses with a maximum rating of 30 amps and a short circuit current rating (SCCR) of 50 kA. The fuse block is constructed from glass-filled polycarbonate for durability and mounts directly via screw mounting. It uses a clip-in fuse installation method with a torque rating of 35 lb-in, accommodating wire sizes from 14 to 2 AWG.
- Key Specifications
- Amperage: 30 A
- Voltage Rating: 600 VAC/VDC
- Number of Poles: 2
- Fuse Class: H/K
- Mounting Type: Direct Screw Mount
- Fuse Installation: Clip-in with Reinforced Clip
- Short Circuit Current Rating (SCCR): 50 kA
- Body Material: Glass Filled Polycarbonate
- Torque Rating: 35 lb-in
- Wire Size Range: 14 to 2 AWG
- Frequency: 50/60 Hz
- ROHS Compliant: Yes
Specifications
- Part Number: 60307
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Fuse Block
- Type : 603
- Voltage : 600
- Amperage : 30
- Mounting : Box
Product Data
- UPC : 754473603076
- GTIN : 00785901409977
- Country of Origin : Mexico
- Dimensions : 3.09 in x 2 in x 7 in
- Weight : 0.04
- Certification : CSA Certified, UL Listed
