Product Info
- Manufacturer:Mersen
- Sub-Category:Fuse Block
Description
60306T
60306T is a 30 amp, 600 volt, 1-pole Class T fuse block manufactured by Mersen Ferraz Shawmut. It is designed for reliable fuse protection in electrical circuits.60306T features a clip-in fuse installation method, glass-filled polycarbonate body material, and spring-reinforced box lugs suitable for aluminum and copper conductors from 14 to 2 AWG. It has a short circuit current rating (SCCR) of 200 kA and meets UL 4248 and UL 512 standards for safety and performance.
- Key Specifications
- Amperage: 30A
- Voltage Rating: 600V AC / 300V DC
- Poles: 1
- Fuse Class: Class T
- Mounting Type: Open style, clip-in fuse installation
- Body Material: Glass-filled polycarbonate (GFPC)
- Wire Size: #14 to #2 AWG Aluminum/Copper
- Interrupt Rating (SCCR): 200 kA
- Torque Rating: 35 lb-in
- Certifications: UL 4248, UL 512, CSA approved
- Dimensions: 3.13" H x 0.97" W x 1.56" D
- Spring Reinforced Box Lugs
Specifications
- Part Number: 60306T
- Manufacturer : Mersen
- Brand : Mersen
- Category : Fuse
- Item Subcategory : Fuse Block
- Family : Amp-Trap
- Type : A6T
- Voltage : 600
- Amperage : 30
Product Data
- UPC : 782001675509
- GTIN : 00782001675509
- Country of Origin : Mexico
- Dimensions : 0.97 in x 3.13 in x 1.56 in
- Weight : 0.08
- Certification : CSA Certified, UL Listed
