Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
5SJ4101-8HG40
5SJ4101-8HG40 is a Siemens 1 Amp miniature circuit breaker designed for reliable overcurrent protection in industrial and commercial applications.5SJ4101-8HG40 features a 1-pole, thermal/magnetic trip unit with a D trip characteristic and a 14kA interrupting rating at 240 VAC. It supports AC/DC voltage operation up to 240 V AC and 60 V DC, with a compact 18 mm width and mounting on a standard 35 mm DIN rail. The breaker complies with UL 489 standards and offers IP20 protection with connected conductors.
- Amperage: 1 A
- Voltage Rating: 240 V AC, 60 V DC
- Number of Poles: 1
- Interrupt Rating: 14 kA at 240 V AC
- Trip Unit: Thermal/Magnetic, D-curve
- Mounting Type: DIN Rail (35 mm standard rail)
- Frame/Series: D-frame, 5SJ4 series
- Dimensions: 90 mm height, 18 mm width, 70 mm depth
- Protection Class: IP20 with connected conductors
- Standards: UL 489, CSA C22.2 No. 5-02
Specifications
- Part Number: 5SJ4101-8HG40
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : 5SJ Series
- Type : 5SJ41
- Voltage : 240
- Amperage : 1
- Phase : 1
- Poles : 1
- AIC rating : 14kA@240V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 75455493231
- GTIN : 00754554932316
- Weight : 0.4
