Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
5NCLPT-1E
5NCLPT-1E is an Eaton Bussmann series current limiting single barrel medium voltage fuse rated at 1 amp and 5.5 kV.
This fuse features a Class E rating with a 63 kA interrupt rating, designed for bolt-on cartridge mounting. It is constructed with fiberglass reinforced resin for durability and provides reliable overcurrent protection in medium voltage applications. The fuse is non-indicating and part of Eaton's NCLPT family, suitable for use where current limiting protection is required.
- Amperage: 1 Amp
- Voltage Rating: 5.5 kV
- Interrupt Rating: 63 kA
- Class: E
- Mounting Type: Cartridge (Bolt-on)
- Construction: Fiberglass Reinforced Resin
- Fuse Type: Current Limiting Single Barrel
- Series/Family: NCLPT
- Indication: Non-indicating
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: 5NCLPT-1E
- Manufacturer : Eaton
- Brand : Eaton
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : CLPT
- Type : NCLPT
- Voltage : 5500
- Amperage : 1
- AIC rating : [email protected]
- Connection : Ferrule
- Diameter : 0.81
- Class Rating : E
- Barrels : 1
Product Data
- UPC : 078211461010
- GTIN : 00782114610107
- Country of Origin : United States
- Dimensions : 143 mm x 20.6 mm x 20.6 mm (Length/Depth x Height x Width)
- Weight : 0.253
- Certification : IEEE Std. C37.41
