Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
5NCLPT-1E-A
5NCLPT-1E-A is an Eaton Bussmann series NCLPT medium voltage fuse rated for 1 ampere and 4.8 kV voltage with a 63 kA interrupting rating. It features a shorter length, non-indicating, single barrel design classified as Class E.
This fuse is constructed with fiberglass reinforced resin and designed for current limiting applications in medium voltage systems. It has a ferrule and bolt-on construction type, providing reliable performance and ease of installation. The 5NCLPT-1E-A is suitable for use in transformer protection and other medium voltage circuit protection needs.
- Amperage Rating: 1 Amp
- Voltage Rating: 4.8 kV
- Interrupt Rating: 63 kAIC
- Fuse Class: E
- Type: NCLPT (Non-indicating Current Limiting)
- Construction: Fiberglass Reinforced Resin
- Design: Single Barrel, Shorter Length
- Mounting: Bolt-on Ferrule
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: 5NCLPT-1E-A
- Manufacturer : Eaton
- Brand : Eaton
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : CLPT
- Type : NCLPT
- Voltage : 5500
- Amperage : 1
- AIC rating : [email protected]
- Connection : Ferrule
- Diameter : 1.6
- Class Rating : E
- Barrels : 1
- Clip Center : 8.1
Product Data
- UPC : 782114299180
- GTIN : 00782114299180
- Country of Origin : Dominican Republic
- Dimensions : 9.5 in x 1.6 in x 1.6 in (Length/Depth x Height x Width)
- Weight : 3
- Certification : IEEE Std. C37.41
