Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
5MCLS-5R-A
5MCLS-5R-A is a medium voltage fuse from the Eaton Bussmann series, designed for motor circuit protection and backup short-circuit protection. This fuse features a Class R rating and is built for reliable performance in demanding electrical environments. The Eaton 5MCLS-5R-A is a current-limiting, single barrel cartridge fuse with a 150A current rating and a 4.8 kV voltage rating. It is engineered for easy installation in existing hardware and provides fast, dependable protection for motor circuits. The fuse is designed to melt within 15 to 35 seconds at 100 times the "R" number per ANSI C37.46, ensuring effective protection against overloads and short circuits.
- Part Number: 5MCLS-5R-A
- Manufacturer: Eaton
- Series: MCLS
- Fuse Type: Class R
- Current Rating: 150A
- Voltage Rating: 4.8 kV
- Mounting Type: Single Barrel
- Application: Motor Circuit Protection
- Interrupting Rating: 50 kA Sym
- Standard: ANSI C37.46
- Features: Current-Limiting, Ferrule
Specifications
- Part Number: 5MCLS-5R-A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : Limitamp
- Type : MCLS
- Voltage : 4800
- Amperage : 150
- AIC rating : [email protected]
- Connection : Bolt In
- Diameter : 3
- Class Rating : R
- Barrels : 1
- Clip Center : 19.2
Product Data
- UPC : 051712470070
- GTIN : 00051712470070
- Country of Origin : United States
- Dimensions : 18.75 in x 4.47 in x 3 in (Length/Depth x Height x Width)
- Weight : 10
- Certification : IEEE Std. C37.41
