Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
5MCLS-24R-B
5MCLS-24R-B is an Eaton Bussmann series MCLS medium voltage current limiting fuse designed for motor circuit protection applications. This Class R cartridge fuse delivers reliable overcurrent protection in industrial and commercial power distribution systems. 5MCLS-24R-B combines high interrupt rating capability with compact design for efficient panel mounting and load protection. The fuse features a 24R designation and dual-barrel construction optimized for motor starting current applications at medium voltage levels. Key Specifications
- Amperage Rating: 450 A
- Voltage Rating: 4.8 kV AC
- Interrupt Rating: 50 kAIC
- Fuse Class: Class R
- Fuse Type: Cartridge
- Series: MCLS
- Mounting Type: Bolt Mount
- Barrels: 2
- Product Length: 18.75 in
- Product Height: 7 in
- Product Width: 3 in
- Product Weight: 20 lb
Specifications
- Part Number: 5MCLS-24R-B
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : Limitamp
- Type : MCLS
- Voltage : 4800
- Amperage : 450
- AIC rating : [email protected]
- Connection : Bolt In
- Diameter : 3
- Class Rating : R
- Barrels : 2
- Clip Center : 19.2
Product Data
- UPC : 786685409375
- Country of Origin : United States
- Dimensions : 18.75 in x 7 in x 3 in (Length/Depth x Height x Width)
- Weight : 20
- Certification : ,IEEE Std. C37.41
