Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
5BHCL-600E
5BHCL-600E is an Eaton Bussmann HCL series medium voltage cartridge fuse rated for 5.5kV AC and 600A, designed for transformer protection and feeder circuit applications. This two-barrel bolt-on fuse delivers reliable overcurrent protection in medium voltage distribution systems with an interrupting rating of 65kA RMS symmetrical. The fuse meets E-rated performance standards for controlled melting characteristics and is suitable for use in switchgear and transformer protection circuits.
- Voltage Rating: 5.5kV AC
- Current Rating: 600A
- Fuse Type: Cartridge
- Series: BHCL (Bolt-on)
- Configuration: Two Barrel
- Interrupting Rating: 65kA RMS Symmetrical
- Diameter: 3 inches
- Application: Transformer Protection, Feeder Circuits, Switchgear
- Performance Class: E-Rated
Specifications
- Part Number: 5BHCL-600E
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : HCL
- Type : BHCL
- Voltage : 5500
- Amperage : 600
- AIC rating : [email protected]
- Diameter : 3
- Barrels : 2
Product Data
- UPC : 662643924701
- GTIN : 00662643924701
- Country of Origin : Dominican Republic
- Dimensions : 25.06 in x 7.6 in x 3 in (Length/Depth x Height x Width)
- Weight : 20
- Certification : ,IEEE Std. C37.41
