Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
5BCLS-5R
5BCLS-5R is an Eaton Bussmann series Class R motor start fuse designed for medium voltage applications.This single barrel fuse features a 150 ampere rating, 4.8 kV voltage rating, and a 50 kA interrupting rating. It is a bolt-in type fuse with a 5R designation, suitable for motor circuit protection. The fuse complies with IEEE Std. C37.41 and is engineered for reliable current limiting performance in motor start applications.
- Amperage Rating: 150 A
- Voltage Rating: 4.8 kV
- Interrupting Rating: 50 kAIC
- Class: R
- Mounting Method: Bolt-in
- Single Barrel, 5R designation
- Series: Eaton Bussmann 5BCLS
- Application: Motor Start
- Certification: IEEE Std. C37.41
Specifications
- Part Number: 5BCLS-5R
- Manufacturer : Eaton
- Brand : Eaton
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : CLS
- Type : BCLS
- Voltage : 5080
- Amperage : 150
- AIC rating : [email protected]
- Connection : Bolt-On
- Diameter : 3
- Class Rating : R
- Barrels : 1
Product Data
- UPC : 782114893661
- GTIN : 00782114893661
- Country of Origin : Dominican Republic
- Dimensions : 19.25 in x 3.6 in x 3 in (Length/Depth x Height x Width)
- Weight : 10
- Certification : IEEE Std. C37.41
