Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
5BCLS-12R
5BCLS-12R is an Eaton Bussmann series Class R medium voltage fuse designed for motor circuit protection with bolt-in mounting and current-limiting capability. This single-barrel fuse delivers reliable overcurrent protection in industrial motor applications requiring fast response and coordination with motor starters. The fuse features an open indicator for quick troubleshooting and is classified as a backup fuse for motor circuit protection in hazardous and non-hazardous locations.
- Amperage: 230A
- Voltage Rating: 4.8 kV nominal (5.0 kV max design)
- Interrupt Rating: 50 kA Sym
- Class: R
- Series: BCLS
- Mounting: Bolt-in
- Configuration: Single barrel
- Designation: 12R
- Application: Motor start protection
- Agency Recognition: UL Recognized (Guide MSSS2, File E96676)
Specifications
- Part Number: 5BCLS-12R
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : CLS
- Type : BCLS
- Voltage : 5080
- Amperage : 230
- AIC rating : [email protected]
- Connection : Bolt-On
- Diameter : 3
- Class Rating : R
- Barrels : 1
Product Data
- UPC : 051712528092
- GTIN : 00782114893708
- Country of Origin : Dominican Republic
- Dimensions : 19.25 in x 3.6 in x 3 in (Length/Depth x Height x Width)
- Weight : 10
- Certification : IEEE Std. C37.41
