5ACLS-9R - Eaton Bussmann ACLS 200A 4.8kV Class R Medium Voltage Fuse

5ACLS-9R

5ACLS-9R is an Eaton Bussmann series ACLS medium voltage current-limiting fuse designed for motor start applications in industrial power distribution systems. Single barrel construction with 9R designation provides reliable overcurrent protection in demanding electrical environments. This Class R fuse features Ampgard mounting technology for secure installation and consistent performance across a wide range of applications requiring medium voltage protection. The fuse delivers 200 ampere rating at 4.8 kilovolt with a 50 kAIC interrupt rating, making it suitable for systems requiring fast current limitation and arc suppression. Engineered to IEEE Std. C37.41 standards, this single barrel fuse combines durability with precision protection for critical motor circuits and distribution equipment.

• Amperage Rating: 200 A
• Voltage Rating: 4.8 kV
• Interrupt Rating: 50 kAIC
• Class: Class R
• Series: ACLS
• Mounting Method: Ampgard
• Configuration: Single Barrel
• Designation: 9R
• Application: Motor Start
• Product Length: 15.9 inches
• Product Weight: 9 pounds
• UPC: 051712527897

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 5ACLS-9R
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Medium Voltage Fuse
• Family : CLS
• Type : ACLS
• Voltage : 5080
• Amperage : 200
• AIC rating : [email protected]
• Connection : Ferrule
• Diameter : 3
• Class Rating : R
• Barrels : 1

Product Data

• UPC : 078667022157
• GTIN : 00786670221579
• Country of Origin : United States
• Dimensions : 15.9 in x 4.2 in x 3 in (Length/Depth x Height x Width)
• Weight : 9
• Certification : ,IEEE Std. C37.41
